IML Spider

The IML Spider is a versatile electrode for direct charging for IML applications.
It consists of a IML Spider block with built-in resistors to prevent accidental
sparking. The IML Spider Block has 8 output ports, with resistors per port,
for connection of up to 8 flexible charging electrodes. An additional output
port is provided for daisy chaining complementary IML Spider Blocks. All
connection ports are equipped with quick connect plugs.

Electrodes are available in lengths of 300 and 500 mm and a special 500 mm
long one that can be tailored during installation by use of a special tool.
Interconnection cables are available in lengths of 0,5 , 1 , 2 and 3 metres.
Connection cable for use with the CM lite type generator are standard 2 , 5
and 10 metres long.

The IML Spider can be used for IML applications in conjunction with IML
generators with a maximum output of 18 kV.

Special connection heads for the CM Micro Easy make it possible to use the IML Spider with the CM Micro Easy or use the CM Micro Easy directly as an IML.

Features

• IML Spider block with 8 positions
• Each output limited with a resistor
• Quick connect cables and electrodes
• Daisy chain possible
• Electrodes custom sizes
• Unlimited combinations with all IML generators
